型号:DS218
工作电压:DC 24V
工作电流:2.5A
开锁时间:3秒
锁芯直径:16mm
碰撞杆长度:15mm
工作原理:通电吸合
材质:铝合金
表面:喷粉
手动开锁:停电仍可使用手动钥匙开锁
电锁尺寸:60*70*118mm
Model: DS 218
Rated Voltage: DC 24V
Materials: Aluminum Die Cast Alloy (Lock)
Cast-iron/ AluminumDie Casting (Lock Stopper)
Surface: Powder Coating
Manual Override: Key Operated Cam Lock to enable manual operating
during power failure
Dimension: 135*190*75 (mm)
Usage: Swing Gate
Bolt Pin Diameter: 16 mm
WorkingRange: 15 mm
Pulse to Open Lock: 3 sec
Operating Current: 2.5A
